STLQ50XX

Maximum ratings

5/18

3

Maximum ratings

Note:

Absolute maximum ratings are those values beyond which damage to the device may occur.

Functional operation under these conditions is not implied.

Table 3.

Absolute maximum ratings

Symbol

Parameter

Value

Unit

DC Input voltage

-0.3 to +14

V

FB voltage

-0.3 to +7

V

ESD

Human body model (all pins)

±2

kV

Junction temperature

-40 to 150

°C

Storage temperature range

-55 to 150

°C

Table 4.

Thermal data

Symbol

Parameter

SOT323-5L

SOT23-5L

Unit

Thermal resistance junction-ambient

°C/W

1.

This value is referred to a 4-layer PCB, JEDEC standard test board.
