STPS5045SG-TR Scheda tecnica(PDF) 1 Page - STMicroelectronics |
|
|
|||||||||||||||||||||||||||||
STPS5045SG-TR Scheda tecnica(HTML) 1 Page - STMicroelectronics |
|
|
1 / 7 page  This is information on a product in full production. June 2012 Doc ID022861 Rev 1 1/7 7 STPS5045S Power Schottky rectifier Datasheet − production data Features ■ Low forward voltage drop ■ Very small conduction losses ■ Negligible switching losses ■ Extremely fast switching ■ Low thermal resistance ■ 200 °C maximum junction temperature ■ Avalanche rated Description This device is a dual center tap Schottky rectifier suited for switch mode power supply and high frequency DC to DC converters. Packaged in D2PAK, this device is especially intended for use in low voltage, high frequency inverters, freewheeling and polarity protection applications. Also ideal for PV cell-bypass diode for junction and smart junction boxes. j Table 1. Device summary Symbol Value IF(AV) 50 A VRRM 45 V Tj (max) 200 °C VF(max) 0.48 V A A K D2PAK STPS5045SG-TR A K A www.st.com |
