Signal descriptions
M24LR16E-R
18/143
Doc ID 018932 Rev 8
Table 2.
Device select code
Device type identifier(1)
1.
The most significant bit, b7, is sent first.
Chip Enable address
RW
b7
b6
b5
b4
b3
b2
b1
b0
Device select code
1010
E2(2)
2.
E2 is not connected to any external pin. It is however used to address the M24LR16E-R as described in
Section 3 and Section 4.
11
RW
Table 3.
Address most significant byte
b15
b14
b13
b12
b11
b10
b9
b8
Table 4.
Address least significant byte
b7
b6
b5
b4
b3
b2
b1
b0
