Maximum rating

M95160 M95160-W M95160-R M95160-F

26/45

Doc ID 022580 Rev 1

Maximum rating

Stressing the device outside the ratings listed in Table 7 may cause permanent damage to

the device. These are stress ratings only, and operation of the device at these, or any other

conditions outside those indicated in the operating sections of this specification, is not

implied. Exposure to absolute maximum rating conditions for extended periods may affect

device reliability.

Table 7.

Absolute maximum ratings

Symbol

Parameter

Min.

Max.

Unit

Ambient operating temperature

–40

130

°C

TSTG

Storage temperature

–65

150

°C

TLEAD

Lead temperature during soldering

See note (1)

Compliant with JEDEC Std J-STD-020 (for small body, Sn-Pb or Pb assembly), with the ST ECOPACK®

7191395 specification, and with the European directive on Restrictions on Hazardous Substances (RoHS)

2002/95/EU.

°C

Output voltage

–0.50

VCC+0.6

Input voltage

–0.50

6.5

VCC

Supply voltage

–0.50

6.5

IOL

DC output current (Q = 0)

IOH

DC output current (Q = 1)

VESD

Electrostatic discharge voltage (human body model)(2)

Positive and negative pulses applied on pin pairs, according to AEC-Q100-002 (compliant with JEDEC Std

JESD22-A114, C1=100 pF, R1=1500

Ω, R2=500 Ω).

4000
