9 / 20 page

ADR360/ADR361/ADR363/ADR364/ADR365/ADR366

Rev. D | Page 9 of 20

ABSOLUTE MAXIMUM RATINGS

TA = 25°C, unless otherwise noted.

Table 8.

Parameter

Rating

Supply Voltage

18 V

Output Short-Circuit Duration to GND

VIN < 15 V

Indefinite

VIN > 15 V

10 sec

Storage Temperature Range

−65°C to +125°C

Operating Temperature Range

−40°C to +125°C

Junction Temperature Range

−65°C to +150°C

Lead Temperature (Soldering, 60 sec)

300°C

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

THERMAL RESISTANCE

is specified for the worst-case conditions, that is, a device

soldered in a circuit board for surface-mount packages.

Table 9. Thermal Resistance

Package Type

θJA

θJC

Unit

5-Lead TSOT (UJ)

230

146

°C/W

ESD CAUTION
