AD637

Rev. K | Page 19 of 20

OUTLINE DIMENSIONS

CONTROLLING DIMENSIONS ARE IN INCHES; MILLIMETER DIMENSIONS

(IN PARENTHESES) ARE ROUNDED-OFF INCH EQUIVALENTS FOR

REFERENCE ONLY AND ARE NOT APPROPRIATE FOR USE IN DESIGN.

0.310 (7.87)

0.220 (5.59)

PIN 1

0.080 (2.03) MAX

0.005 (0.13) MIN

SEATING

PLANE

0.023 (0.58)

0.014 (0.36)

0.060 (1.52)

0.015 (0.38)

0.200 (5.08)

MAX

0.200 (5.08)

0.125 (3.18)

0.070 (1.78)

0.030 (0.76)

0.100 (2.54)

BSC

0.150

(3.81)

MIN

0.765 (19.43) MAX

0.320 (8.13)

0.290 (7.37)

0.015 (0.38)

0.008 (0.20)

Figure 32. 14-Lead Side-Brazed Ceramic Dual In-Line Package [SBDIP]

(D-14)

Dimensions shown in inches and (millimeters)

CONTROLLING DIMENSIONS ARE IN INCHES; MILLIMETER DIMENSIONS

(IN PARENTHESES) ARE ROUNDED-OFF INCH EQUIVALENTS FOR

REFERENCE ONLY AND ARE NOT APPROPRIATE FOR USE IN DESIGN.

0.310 (7.87)

0.220 (5.59)

0.005 (0.13) MIN

0.098 (2.49) MAX

0.100 (2.54) BSC

15°

0°

0.320 (8.13)

0.290 (7.37)

0.015 (0.38)

0.008 (0.20)

SEATING

PLANE

0.200 (5.08)

MAX

0.785 (19.94) MAX

0.150

(3.81)

MIN

0.200 (5.08)

0.125 (3.18)

0.023 (0.58)

0.014 (0.36)

0.070 (1.78)

0.030 (0.76)

0.060 (1.52)

0.015 (0.38)

PIN 1

Figure 33. 14-Lead Ceramic Dual In-Line Package [CERDIP]

(Q-14)

Dimensions shown in inches and (millimeters)
