Data Sheet
AD8215
Rev. A | Page 5 of 16
PIN CONFIGURATION AND FUNCTION DESCRIPTIONS
5
1
2
5
6
8
Figure 2. Metallization Diagram
–IN
1
GND
2
NC
3
NC
4
+IN
8
NC
7
V+
6
OUT
5
NC = NO CONNECT
AD8215
TOP VIEW
(Not to Scale)
Figure 3. Pin Configuration
Table 3. Pin Function Descriptions
Pin No.
Mnemonic
X
Y
Description
1
−IN
−228
+519
Inverting Input.
2
GND
−273
−251
Ground.
3, 4, 7
NC
N/A
N/A
No Connect.
5
OUT
+265
−466
Buffered Output.
6
V+
+273
−266
Supply.
8
+IN
+229
+519
Noninverting Input.
