TN805, TN815, TS820, TYN608

Package information

Doc ID 7476 Rev 7

7/13

3

Package information

●

Epoxy meets UL94, V0

●

Lead-free packages

●

Recommended torque: 0.4 to 0.6 N·m

In order to meet environmental requirements, ST offers these devices in different grades of

specifications, grade definitions and product status are available at: www.st.com.

Figure 18.

Footprint (dimensions in mm)

Table 6.

DPAK dimensions

Ref.

Dimensions

Millimeters

Inches

Min.

Max.

Min.

Max.

A

2.20

2.40

0.086

0.094

A1

0.90

1.10

0.035

0.043

A2

0.03

0.23

0.001

0.009

B

0.64

0.90

0.025

0.035

B2

5.20

5.40

0.204

0.212

C

0.45

0.60

0.017

0.023

C2

0.48

0.60

0.018

0.023

D

6.00

6.20

0.236

0.244

E

6.40

6.60

0.251

0.259

G

4.40

4.60

0.173

0.181

H

9.35

10.10

0.368

0.397

L2

0.80 typ.

0.031 typ.

L4

0.60

1.00

0.023

0.039

V2

0°

8°

0°

8°

H

L4

G

B

L2

E

B2

D

A1

R

R

C

A

C2

0.60 MIN.

V2

A2

6.7

6.7

3

3

1.6

1.6

2.3

2.3
