ADCLK914

Rev. A | Page 2 of 12

TABLE OF CONTENTS

Features .............................................................................................. 1

Applications....................................................................................... 1

Functional Block Diagram .............................................................. 1

General Description ......................................................................... 1

Revision History ............................................................................... 2

Specifications..................................................................................... 3

Electrical Characteristics............................................................. 3

Absolute Maximum Ratings............................................................ 5

Thermal Resistance ...................................................................... 5

ESD Caution.................................................................................. 5

Pin Configuration and Function Descriptions............................. 6

Typical Performance Characteristics ..............................................7

Applications Information .................................................................9

Power/Ground Layout and Bypassing........................................9

HVDS Output Stage......................................................................9

Interfacing to High Speed DACs.................................................9

Optimizing High Speed Performance ........................................9

Random Jitter.................................................................................9

Typical Application Circuits ..................................................... 10

Outline Dimensions ....................................................................... 11

Ordering Guide .......................................................................... 11

REVISION HISTORY

10/08—Rev. 0 to Rev. A

Changes to Input Low Voltage Parameter, Table 1....................... 3

Changes to Output High Voltage Parameter, Table 1 ................ 3

Changes to Output Low Voltage Parameter, Table 1.................. 3

Output Differential Range Parameter, Table 1 ............................ 3

Changes to Absolute Maximum Ratings Section ........................ 5

7/08—Revision 0: Initial Version
