1. Introduction

The PCB.SMAFSTJ.B.HT connector was designed to be surface mounted on a PCB, it has a Solder

Post for connection. The connector pin is directly soldered onto pads on the PCB. The connector

is a standard SMA (F) Jack. The SMA connector is the most popular type connector for RF

applications. Taoglas connectors are all RoHS compliant.

2. Specification

ELECTRICAL

Impedance

50Ω

Frequency Range

0~12.4 GHz

Working Voltage

Max. 335 Vrms

Dielectric withstanding Voltage

≤1000 Vrms

Insulation Resistance

≥5000M Ω

MECHANICAL

Connector Dimension

10.4 X 5.35 mm

Connector Pin Diameter

1.27 mm

Max. Thickness PCB acceptable

0.8 mm

Connector Type

SMA (F)

ENVIRONMENTAL

RoHS compliant
