Notes:
The following are typical values:
1. R
OSC = 2.0 M OHM.
2. B for N (NPN transistor) > 130.
3. SP = 8 OHM 1/4W.
4. Piezo buzzer resonant frequency = 1 KHz.
APPLICATION CIRCUITS
Vcc
GND
TG1
TG2
TG3
TG4
OSC
COUT
SP
ROSC
ROSC
Vcc
GND
OSC
CDS
IRP
SBT
COUT
SP
SW4
SW3
SW7
SW6
SW5
SW8
SW2
SW1
Figure 6. CDS Application and Additional Trigger
