SRP6540 Series - Shielded Power Inductors

Packaging Specifications

EMBOSSED

CARRIER

EMBOSSED

CAVITY

16.0

(.630)

CARRIER TAPE WIDTH

DIMENSIONS:

MM

(INCHES)

03/13

18.0 + 0

(.709 +0)

22.4

(.882)

2.0

± 0.5

(.079

± .020)

50.0 - 0

(1.969 - 0)

330.0

(13.00)

DIA.

13.0

± 0.5

(.512

± .020)

DIA.

21.0 ± 0.8

(.827 ± .031)

13.0

± 0.5

(.512

± .020)

DIA.

12.0

(.472)

END

START

4.0

(.157)

USER DIRECTION OF FEED

NO COMPONENT

COMPONENTS

200

(7.874)

NO COMPONENT

400

(15.748)

1200 PIECES PER REEL

Asia-Pacific:

Tel: +886-2 2562-4117 • Fax: +886-2 2562-4116

Europe:

Tel: +41-41 768 5555 • Fax: +41-41 768 5510

The Americas:

Tel: +1-951 781-5500 • Fax: +1-951 781-5700

www.bourns.com

Specifications are subject to change without notice.

The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.

Users should verify actual device performance in their specific applications.
