3 / 4 page ![]() LR1148 CMOS IC UNISONICTECHNOLOGIESCO.,LTD 3 of 4 www.unisonic.com.tw QW-R502-A74.a ABSOLUTE MAXIMUM RATING (TA=25°С) PARAMETER SYMBOL RATINGS UNIT Supply Voltage VIN 6.5 V Power Dissipation PD 360 mW Junction Temperature TJ +125 °С Ambient Operating Temperature TOPR -40 ~ +85 °С Storage Temperature TSTG -65 ~ +150 °С Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged. Absolute maximum ratings are stress ratings only and functional device operation is not implied. THERMAL DATA PARAMETER SYMBOL RATINGS UNIT Junction to Ambient θJA 260 C/W Junction to Case θJC 81 C/W ELECTRICAL CHARACTERISTICS (CIN = 1µF, COUT =1µF, TA= 25°C, unless otherwise specified)(Note 1) PARAMETER SYMBOL TEST CONDITIONS MIN TYP MAX UNIT Input Voltage(Note 2) VIN 2.3 6 V Output Voltage Accuracy (Preset Mode) VOUT TA=25°С , IOUT= 1mA ~0.6A -2 2 % TA=0~85°С, IOUT= 1mA~0.6A -3 3 % Maximum Output Current IOUT 600 mA Short-Circuit Current Limit ILIMIT VOUT=0V 1 A Ground Pin Current IGND IOUT = 0mA 70 µA IOUT= 1mA to 600mA 80 µA Dropout Voltage (Note3) VD IOUT=600mA VOUT(NOM)<=1.8V 500 1200 mV 1.8V<VOUT(NOM) 200 450 Line Regulation (Note4) OUT IN OUT V × ∆V ∆V VIN=VOUT+VD~6V 0.08 0.55 %/V Load Regulation(Note4,5) ∆VOUT VIN=VOUT+VD, IOUT=10mA~600mA 0.25 1.0 % Output Voltage Noise eN f=10Hz to100kHz, CBP=0.1nF 24 µVRM S Shutdown Supply Current IOFF EN=GND 0.01 5 µA Shutdown Threshold VIH 2 V VIL 0.4 V Thermal Shutdown Temperature TSHDN 170 °С Thermal Shutdown Hysteresis DTSHDN 20 °С ADJ Voltage VREF Measured on ADJ, IOUT =10mA 0.774 0.8 0.826 V ADJ Mode Threshold 100 mV Adjustable Output Voltage 0.8 5 V Note: 1. Specifications are production tested at TA=25°C. Pecifications over the -40°C to 85°C operating temperature range are assured by design, characterization and correlation with Statistical Quality Controls(SQC). 2. The minimum operating value for VIN is equal to either [VOUT(NOM)+VD] or 2.3V,whichever is greater 3. Dropout voltage is defined as the voltage from the input to output when output is 2% below the nominal value. 4. Output voltage line regulation is defined as the change in output voltage from the nominal value resulting from a change in the input line voltage. Output voltage load regulation is defined as the change in output voltage from the nominal value as the load current increases from no load to full load. 5. Regulation is measured at constant junction temperature by using a 20ms current pulse. Devices are tested for load regulation in the load range from 10mA to 600mA |
|
|
