UNISONIC TECHNOLOGIES CO., LTD

LR1148

CMOS IC

www.unisonic.com.tw

1 of 4

QW-R502-A74.a

600mA LOW DROPOUT LINEAR

REGULATOR



DESCRIPTION

The UTC LR1148 belonged to low-noise, low-dropout, linear

regulators operate from 2.3V to 6V input and are guaranteed to

deliver 600mA. Wide range of preset output voltage options are

available. Built-in low on-resistance transistor provides low dropout

voltage and large output current. The UTC LR1148 is designed and

optimized for battery-powered systems to work with low noise.

The UTC LR1148 consumes less than 0.01μA in shutdown

mode. Other features include ultra low dropout voltage, current

limiting protection, thermal shutdown protection and high ripple

rejection ratio.



FEATURES

* 600mA Guaranteed Output Current

* 0.01μA Shutdown Current

* Ultra Low Dropout Voltage

* Low Temperature Coefficient

* Current Limiting Protection

* Thermal Shutdown Protection

* Excellent Line/Load Transient



ORDERING INFORMATION

Note: Pin Assignment: I:VIN O:VOUT G:GND S:EN A: ADJ

LR1148L-xx-AF5-R

(1)Packing Type

(2)Package Type

(3)Output Voltage Code

(1) R: Tape Reel

(2) AF5: SOT-25

(3) xx: refer to Marking Information

(4) L: Lead Free, G: Halogen Free

(4)Lead Free



MARKING INFORMATION

PACKAGE

VOLTAGE CODE

MARKING

SOT-25

A D : A DJ

Ordering Number

Package

Pin Assignment

Packing

Lead Free

Halogen Free

1234

5

LR1148L-xx-AF5-R

LR1148G-xx-AF5-R

SOT-25

I

G

S

A

O

Tape Reel
