UNISONIC TECHNOLOGIES CO., LTD

2SD1782

Preliminary

NPN EPITAXIAL SILICON TRANSISTOR

www.unisonic.com.tw

1 of 3

QW-R206-107.a

POWER NPN TRANSISTOR



DESCRIPTION

The UTC 2SD1782 is an NPN silicon transistor. it uses UTC’s

advanced technology to provide customers with high collector-emitter

breakdown voltage, low collector-emitter saturation voltage and high

DC current gain, etc.



FEATURES

* High collector-emitter breakdown voltage

* Low collector-emitter saturation voltage

* High DC current gain



ORDERING INFORMATION

Ordering Number

Package

Pin Assignment

Packing

Lead Free

Halogen Free

1

2

3

2SD1782L-x-AE3-R

2SD1782G-x-AE3-R

SOT-23

E

B

C

Tape Reel



MARKING (For SOT-23 Package)

D17

L: Lead Free

G: Halogen Free
