SS14W

Preliminary

DIODE

UNISONICTECHNOLOGIESCO.,LTD

2 of 3

www.unisonic.com.tw

QW-R601-095.a



ABSOLUTE MAXIMUM RATINGS (TA =25°C, unless otherwise specified.)

PARAMETER

SYMBOL

RATINGS

UNIT

Recurrent Peak Reverse Voltage

VRRM

RMS Voltage

VRMS

Average Forward Current

.375” (9.5mm) lead length at

TL=75°C

IF(AV)

1.0

Peak Forward Surge

Current

8.3ms single half sine-wave

superimposed on rated load

(JEDEC method)

IFSM

Storage Temperature

TSTG

-40~+150

°C

Operating Junction Temperature

-40~+150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



THERMAL CHARACTERISTICS (TA =25°C, unless otherwise specified.) (Note)

PARAMETER

SYMBOL

RATINGS

UNIT

Junction to Ambient

θJA

°C/W

Junction to Case

θJC

°C/W



ELECTRICAL CHARACTERISTICS (TA=25°C unless otherwise specified.)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP MAX UNIT

Forward Voltage (Note)

IF=1.0A

0.5

DC Reverse Current at Rated DC

Blocking Voltage

TJ=25°C

0.5

TJ=100°C

Note: Pulse test with PW=300μs, 1% duty cycle.
