E-86

Series

ECONOLINE

DC/DC-Converter

Specifications - Continued

Typical Characteristics

100

0

40%

0%

100%

40

Efficiency / Load

60%

80%

20%

20

60

80

Total Output current (%)

2405

1205

0505

3.305

Deviation / Load

-10.000

40%

0%

100%

60%

80%

20%

-5.000

Total Output current (%)

0505

0.000

5.000

10.000

15.000

20.000

25.000

1205

2405

3.305

R2S-xx05

Isolation Voltage

(tested for 1 second)

1000VDC

(rated for 1 minute***)

500VAC / 60Hz

Isolation Voltage

(tested for 1 second)

3000VDC

(rated for 1 minute***)

1500VAC / 60Hz

Isolation Capacitance

115pF max.

Isolation Resistance

(Viso 500V)

10 G

Ω min.

Short Circuit Protection

1 Second

P-Suffix

Continuous

Operating Temperature Range (free air convection)

-40°C to +100°C (see Graph)

Storage Temperature Range

-55°C to +125°C

Reflow Temperature

ROHS compliant

245°C (30 sec), peak 255°C (5 sec) max.

Vapour Phase Process

(for more details see Application Notes)

230°C (90 sec) max.

Relative Humidity

95% RH

Package Weight

R2S, R2S8

1.4g

R2D, R2D10

1.5g

R2S12, R2D12

1.6g

Packing Quantity

R2S, R2S8

39 pcs per Tube

R2S12, R2D, R2D10, R2D12

33 pcs per tube

All Types

250 pcs per Reel

MTBF (+25°C)

using MIL-HDBK 217F

(+85°C)

using MIL-HDBK 217F

Certifications

CB Test Report

Report: US/14402/UL

UL General Safety

Report: E308085

UL 60950-1 2nd Ed.

CUL General Safety

C22.2 No. 60950-1-03

EN Medical Safety

Report: MDD1205098-2 + RM1205098-2

IEC/EN 60601-1 3rd Ed.

Medical Report + ISO14971 Risk Assessment

EN General Safety

Report: SPCLVD 1211033-3

EN60950-1: 2006 + A12:2011

Conducted / Radiated Emissions

EN55022

Level A

Application Notes chapter "MTBF"

100

0

40%

0%

100%

40

Efficiency / Load

60%

80%

20%

20

60

80

Total Output current (%)

2405

1205

0505

3.305

Deviation / Load

-10.000

40%

0%

100%

60%

80%

20%

-5.000

Total Output current (%)

0505

0.000

5.000

10.000

15.000

20.000

25.000

1205

2405

3.305

R2D-xx05

Notes

Note 1

Maximum capacitive load is defined as the capacitive load that will allow start up in under 1 second without damage to the converter.

REV: 1/2014
