47 / 50 page

DocID11124 Rev 21

47/50

M95512-W M95512-R M95512-DR M95512-DF

Part numbering

Table 26. Ordering information scheme

Example:

M95512

W MN 6

P /K

Device type

M95 = SPI serial access EEPROM

Device function

512 = 512 Kbit (65536 x 8)

512-D = 512 Kbit plus Identification page

Operating voltage

W = VCC = 2.5 to 5.5 V

R = VCC = 1.8 to 5.5 V

F = VCC = 1.7 to 5.5 V

Package(1)

1. All packages are ECOPACK2® (RoHS compliant and halogen-free).

MN = SO8 (150 mil width)

DW = TSSOP8 (169 mil width)

MC = UFDFPN8 (MLP8)

CS = WLCSP

Device grade

6 = Industrial temperature range, –40 to 85 °C

Device tested with standard test flow

Option

blank = Standard packing

T = Tape and reel packing

Plating technology

G or P = RoHS compliant and halogen-free

(ECOPACK®)

Process(2)

2. The process letters apply to WLCSP devices only. The process letters appear on the device

package (marking) and on the shipment box. Please contact your nearest ST Sales Office for

further information.

/K= Manufacturing technology code
