UNISONIC TECHNOLOGIES CO., LTD

4051

CMOS IC

www.unisonic.com.tw

1 of 8

Copyright © 2015 Unisonic Technologies Co., LTD

QW-R502-054.D

8-CHANNEL ANALOG

MULTIPLEXERS/DEMULTIPLEXERS



DESCRIPTION

UTC 4051 is single 8-channel analog multiplexers/demultiplexers

for application as digitally–controlled analog switches.

The device has three binary control inputs and an inhibit input. It

feature low ON impedance and very low OFF leakage current.

Control of analog signals up to the complete supply voltage range

can be achieved.



FEATURES

* Break-Before-Make Switching Eliminates Channel Overlap.

* Linearized Transfer Characteristics

* Implement an SP8T solid state switch effectively.

* Pin–to–Pin Replacement for CD4051



ORDERING INFORMATION

Ordering Number

Package

Packing

Lead Free

Halogen Free

4051L-D16-T

4051G-D16-T

DIP-16

Tube

-

4051G-S16-R

SOP-16

Tape Reel

-

4051G-P16-R

TSSOP-16

Tape Reel

(1) T: Tube, R: Tape Reel

(2) D16: DIP-16, S16: SOP-16, P16: TSSOP-16

(3) L: Lead Free, G: Halogen Free and Lead Free

4051L-D16-T

(1)Packing Type

(2)Package Type

(3)Green Package



MARKING

DIP-16

SOP-16 / TSSOP-16
