U2429
CMOS IC
UNISONICTECHNOLOGIESCO.,LTD
2 of 6
www.unisonic.com.tw
QW-R502-031.C
PIN CONFIGURATION
PIN DESCRIPTION
PIN NO
PIN NAME
DESCRIPTION
1
VIN 1
1-ch input pin
2
VOUT1
1-ch output pin
3
GND
Ground pin
4
DATA
Control data input pin. Inputs data in synchronization with clock.
5
CLOCK
Clock input pin for transferring serial data.
6
VCC
Power supply pin. Stabilize the pin with decoupling capacitor.
7
VOUT2
2-ch output pin
8
VIN2
1-ch input pin
BLOCK DIAGRAM
