CONREVSMA014-R178 Scheda tecnica(PDF) 1 Page - List of Unclassifed Manufacturers |
|
|
|||||||||||||||||||||||||||||
CONREVSMA014-R178 Scheda tecnica(HTML) 1 Page - List of Unclassifed Manufacturers |
|
|
1 / 1 page  NOTES: (UNLESS OTHERWISE SPECIFIED) 1. ALL DIMENSIONS ARE IN INCHES [mm]. 2. DIMENSIONS APPLY AFTER FINISHING. 3. MANUFACTURE TO BE COMPLIANT WITH EU RoHS DIRECTIVE. 4. SAFETY BREAK ALL SHARP CORNERS AND EDGES .02 MAXIMUM. REVISIONS REV A Add heat shrink, new frame, revised stripping instruct./dims 4/26/10 CJ DESCRIPTION DATE APPV SHEET 1 OF 1 LDCFDCC_A SCALE: 2:1 TITLE: SIZE DWG. NO. REV DO NOT SCALE DRAWING ANGLES: 1 TOLERANCES: .020 [0.50]-.200 [5.00]= .008 [0.20] .200 [5.00]-1.200 [30.00]= .016 [0.40] 1.20 [30.0]-4.75 [120.0]= .024 [0.60] 4.75 [120.0]-12.40 [315.0]= .040 [1.0] DRAWN: ENGR: DT: DT: MATERIAL: FINISH: PROJECTION: : THIS DRAWING CONTAINS PROPRIETARY INFORMATION THAT IS THE SOLE PROPERTY OF CONNECTOR CITY, AND SHALL BE TREATED AS SUCH. NO DISCLOSURE OR REPRODUCTION OF THIS DOCUMENT IS PERMITTED, IN WHOLE OR IN PART, WITHOUT THE EXPRESS WRITTEN PERMISSION OF CONNECTOR CITY OR ITS DESIGNATED AGENTS. 159 ORT LANE MERLIN, OR 97532 Description Material Finish Body Pin Insulation Nickel Teflon Gold Teflon Spacer Teflon Teflon O Ring Rubber Si Rubber Washer Nickel Brass Nut Nickel Brass Support Nickel Brass Heat Shrink Black Polyolefin Brass BE CU CONREVSMA014-R178 RP-SMA FEMALE BULKHEAD MOUNT CABLE END CRIMP WITH O-RING FOR RG178 CABLE CJ 4/26/10 0.197 (5.00) 0.032 (0.80) RECOMMENDED CABLE STRIPPING DIMENSIONS 0.217 (5.50) RG-178 Cable Ø0.256 (6.50) 0.236 (6.00) RECOMMENDED MOUNTING HOLE 0.065 (1.65) 1/4-36UNS-2B THREADS H0.315 (8.00) 0.020 (0.50) Ø0.402 (10.20) 0.433 (11.00) FLAT 0.228 (5.80) 0.197 (5.00) 0.248 (6.30) 0.083 (2.10) 0.417 (10.60) 0.748 (19.00) FLAT 0.228 (5.80) Ø0.102 (2.60) Ø0.236 (6.00) H0.433 (11.00) 1/4"-36UNS-2A THREADS CONREVSMA014-R178 ASSEMBLY INSTRUCTIONS 1. Strip the cable to the recommended dimensions. 2. Slide the coax into the support until the outside insulation bottoms out against the inside shoulder of the support. 3. Solder the support onto the braid. 4. Place the spacer onto the center conductor. 5. Solder or crimp the pin onto the center conductor. 6. Insert the pin, center conductor, spacer, and support into the body until the top of the pin is flush to end of the body. 7. Crimp the tail of the body onto the support with a 0.093” hex crimp tool. SPACER SUPPORT SIDE VIEW BACK VIEW WASHER NUT HEAT SHRINK 0.787 (20.00) Ø0.118 (3.00) Ø0.049 (1.24) 0.500 (12.70) Ø0.020 (0.50) PIN |
