LS3718

CMOS IC

UNISONICTECHNOLOGIESCO.,LTD

4 of 8

www.unisonic.com.tw

QW-R121-015.B



PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

-0.5~+7.0

V

Input Voltage

V

Output Voltage

V

Output Current

±25

mA

Power Dissipation

500

mW

Junction Temperature

+125

°C

Operating Temperature

-25 ~ +85

°C

Storage Temperature

-40 ~ +150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

Operating Voltage

4.5

5.5

V

Operating Current

0.1

mA

Input Leakage Current

-10

10

μA

High-Level

V

Input Voltage

Low-Level

High-Level

4.0

4.97

V

Output Voltage

Low-Level

SO Terminal

0.11

0.4

V

High-Level

0.5

1.5

V

0.3

0.8

Output Voltage

Low-Level

P1~P20

Terminals (Note)

0.2

0.4

Note: Specified value represent output current per pin. When use, total current consideration and less than power

dissipation rating operation should be required.



SWITCHING CHARACTERISTICS

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

Data Set-up Time

DATA-CLK

20

ns

Data Hold Time

CLK-DATA

20

ns

Set-up Time

STB -CLK

30

ns

Hold Time

CLK- STB

30

ns

CLK-SO

70

ns

100

ns

80

ns

Output Delay Time

80

ns

Max. Operating Frequency

5

MHz
