UNISONIC TECHNOLOGIES CO., LTD

U74LVC1G19

CMOS IC

www.unisonic.com.tw

1 of 5

QW-R502-356.A

1-OF-2

DECODER/DEMULTIPLEXER

DESCRIPTION

The U74LVC1G19 is a 1-of-2 decoder / demultiplexer with a

common output enable. This device buffers the data on input A and

passes it to the outputs 1Y and 2Y when the enable input signal is

LOW.

This device is fully specified for partial power-down applications

using Ioff. The Ioff circuitry disables the outputs, preventing the

damaging backflow current through the device when it is powered

down.

FEATURES

* Operate from 1.65V to 5.5V

* Inputs accept voltages to 5.5V

* Low power dissipation, ICC=10μA (Max)

* ±24mA output drive(VCC=3V)

ORDERING INFORMATION

Ordering Number

Package

Packing

Lead Free

Halogen Free

U74LVC1G19L-AL6-R

U74LVC1G19G-AL6-R

SOT-363

Tape Reel

U74LVC1G19L-AL6-R

(1)Packing Type

(2)Package Type

(3)Lead Free

(1) R: Tape Reel

(2) AL6: SOT-363

(3) Halogen Free, L: Lead Free

MARKING
