3 / 9 page ![]() UD4606 Power MOSFET UNISONICTECHNOLOGIESCO.,LTD 3 of 9 www.unisonic.com.tw QW-R502-144.D ABSOLUTE MAXIMUM RATINGS (TA = 25°С, unless otherwise specified) N-CHANNEL PARAMETER SYMBOL RATINGS UNIT Drain-Source Voltage VDSS 30 V Gate-Source Voltage VGSS ±20 V Continuous Drain Current (Note2) ID 6.9 A Pulsed Drain Current (Note2) IDM 30 A Power Dissipation DIP-8 PD 2.5 W SOP-8 2 W Junction Temperature TJ +150 °С Storage Temperature TSTG -55 ~ +150 °С P-CHANNEL PARAMETER SYMBOL RATINGS UNIT Drain-Source Voltage VDSS -30 V Gate-Source Voltage VGSS ±20 V Continuous Drain Current (Note 2) ID -6 A Pulsed Drain Current (Note 2) IDM -30 A Power Dissipation DIP-8 PD 2.5 W SOP-8 2 W Junction Temperature TJ +150 °С Storage Temperature TSTG -55 ~ +150 °С Notes: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged. Absolute maximum ratings are stress ratings only and functional device operation is not implied. 2. Surface Mounted on 1in 2 pad area, t≤10sec THERMAL DATA PARAMETER SYMBOL MIN TYP MAX UNIT Junction to Ambient (Note) DIP-8 θJA 74 110 °С/W SOP-8 67 80 °С/W Note: Surface Mounted on 1in 2 pad area, t≤10sec ELECTRICAL CHARACTERISTICS (TA =25°C, unless otherwise specified) N-CHANNEL PARAMETER SYMBOL TEST CONDITIONS MIN TYP MAX UNIT OFF CHARACTERISTICS Drain-Source Breakdown Voltage BVDSS VGS=0V, ID=250uA 30 V Drain-Source Leakage Current IDSS VDS=24V, VGS=0V 1 uA Gate-Source Leakage Current IGSS VDS=0V, VGS=±20V 100 nA ON CHARACTERISTICS Gate Threshold Voltage VGS(TH) VDS=VGS, ID=250uA 1 1.9 3 V Drain-Source On-State Resistance RDS(ON) VGS=10V, ID=6.9A 22.5 28 mΩ VGS=4.5V, ID=5A 34.5 42 mΩ DYNAMIC CHARACTERISTICS Input Capacitance CISS VGS=0V,VDS=15V,f=1.0MHz 680 pF Output Capacitance COSS 102 pF Reverse Transfer Capacitance CRSS 77 pF SWITCHING CHARACTERISTICS Turn-ON Delay Time (Note2) tD(ON) VDS=15V, VGS=10V, RG=3Ω, RL=2.2Ω 4.6 ns Turn-ON Rise Time tR 4.1 ns Turn-OFF Delay Time tD(OFF) 20.6 ns Turn-OFF Fall Time tF 5.2 ns |
|
|
