2 / 5 page ![]() UT8067 Preliminary Power MOSFET UNISONICTECHNOLOGIESCO.,LTD 2 of 5 www.unisonic.com.tw QW-R210-005.b ABSOLUTE MAXIMUM RATINGS (TA=25°C, unless otherwise specified) PARAMETER SYMBOL RATINGS UNIT Drain-Source Voltage VDSS 30 V Gate-Source Voltage VGSS ±20 V Continuous (Note 1) ID 9 A Drain Current Pulsed (Note 1) IDM 36 A Avalanche Current IAR 9 A Single Pulsed Avalanche Energy (Note 2) EAS 21 mJ Power Dissipation (t=10s) PD 1.0 W Junction Temperature TJ 150 °C Storage Temperature Range TSTG -55~+150 °C Notes: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged. Absolute maximum ratings are stress ratings only and functional device operation is not implied. 2. Repetitive Rating: Pulse width limited by maximum junction temperature 3. L = 0.2mH, IAS = 9A, VDD = 24V, RG = 1.2Ω, Starting TJ = 25°C THERMAL CHARACTERISTICS PARAMETER SYMBOL RATINGS UNIT Junction to Ambient (t=10s) θJA 125 °C/W Note: Surface Mounted on 25.4 mm×25.4 mm×0.8mm FR4 Board. ELECTRICAL CHARACTERISTICS (TA=25°C, unless otherwise specified) PARAMETER SYMBOL TEST CONDITIONS MIN TYP MAX UNIT OFF CHARACTERISTICS BVDSS ID=10mA, VGS=0V 30 V Drain-Source Breakdown Voltage BVDSX ID=10mA, VGS=-20V 15 V Drain-Source Leakage Current IDSS VDS=30V, VGS=0V 10 µA Forward VGS=+20V, VDS=0V +0.1 µA Gate-Source Leakage Current Reverse IGSS VGS=-20V, VDS=0V -0.1 µA ON CHARACTERISTICS Gate Threshold Voltage VGS(TH) VDS=10V, ID=0.1mA 1.3 2.3 V VGS=4.5V, ID=4.5A 26 33 Static Drain-Source On-State Resistance RDS(ON) VGS=10V, ID=4.5A 20 25 mΩ DYNAMIC PARAMETERS Input Capacitance CISS 690 pF Output Capacitance COSS 120 pF Reverse Transfer Capacitance CRSS VGS=0V, VDS=10V, f=1.0MHz 28 pF SWITCHING PARAMETERS VDD≈24V, VGS=10V, ID=9A 9.5 nC Total Gate Charge QG VDD≈24V, VGS=5V, ID=9A 4.7 nC Gate to Source Charge QGS 2.2 nC Gate to Drain Charge QGD VDD≈24V, VGS=10V, ID=9A 0.9 nC Gate Resistance RG VGS=0V, VDS=10V, f=5MHz 3.4 5.1 Ω Turn-ON Delay Time tD(ON) 6.7 ns Rise Time tR 2.1 ns Turn-OFF Delay Time tD(OFF) 15 ns Fall-Time tF 2.1 ns SOURCE- DRAIN DIODE RATINGS AND CHARACTERISTICS Drain-Source Diode Forward Voltage VSD ISD=9A, VGS=0V -1.2 V Continuous Drain-Source Current ISD 36 A Notes: 1. Pulse Test: Pulse width ≤ 300µs, Duty cycle ≤ 2% 2. Essentially independent of operating temperature |
|
|
