BAS85

DIODE

UNISONICTECHNOLOGIESCO.,LTD

2 of 3

www.unisonic.com.tw

QW-R202-015.B



ABSOLUTE MAXIMUM RATINGS

PARAMETER

SYMBOL

RATINGS

UNIT

Continuous Reverse Voltage

Continuous Forward Current @ TA=25°C (Note 1)

200

Peak Forward Current @ TA=25°C (Note 1)

IFM

300

Non-Repetitive Peak Forward Current

@ tp<1s, TA=25°C (Note 1)

IFSM

Power Dissipation @ TA=65°C (Note 1)

200

Junction Temperature

125

°C

Operating Ambient Temperature

-55~+125

°C

Storage Temperature

TSTG

-55~+150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



THERMAL DATA

PARAMETER

SYMBOL

RATINGS

UNIT

Junction to Ambient (Note 1)

θJA

430

°C/W



ELECTRICAL CHARACTERISTICS

PARAMETER

SYMBOL

TEST CONDITIONS

MIN TYP MAX UNIT

Reverse Breakdown Voltage

Forward Voltage (Note 2)

IF=0.1mA

0.24

IF=1mA

0.32

IF=10mA

0.4

IF=30mA

0.5

IF=100mA

0.8

Leakage Current

VR=25V

2.0

μA

Reverse Recovery Time

trr

IF=10mA,IR=10mA, IR=1mA

Junction Capacitance

f=1MHz, VR=1V

Notes: 1. Valid provided that leads at a distance of 4mm from case are kept at ambient temperature

2. Pulsed test: tP<300μs; δ<2%.
