UNISONIC TECHNOLOGIES CO., LTD

MBR3200

Preliminary

DIODE

www.unisonic.com.tw

1 of 3

QW-R202-020.b

SCHOTTKY BARRIER

RECTIFIER



DESCRIPTION

The UTC MBR3200 is a schottky barrier rectifier, it uses UTC’s

advanced technology to provide customers with low forward voltage

drop, high current capability and high efficiency, etc.

The UTC MBR3200 is suitable for free wheeling, high frequency

inverters, low voltage and polarity protection applications.



FEATURES

* Low forward voltage drop

* High efficiency

* Low power loss

* High surge capability



SYMBOL



ORDERING INFORMATION

Ordering Number

Pin Assignment

Lead Free

Halogen Free

Package

1

2

Packing

MBR3200L-SMC-R

MBR3200G-SMC-R

SMC

K

A

Tape Reel

MBR3200L-Z21D-B

MBR3200G-Z21D-B

DO-201AD

K

A

Tape Box

Note: Pin Assignment: A: Anode

K: Cathode

MBR3200L-SMC-R

(1)Packing Type

(2)Package Type

(1) R: Tape Reel, B: Tape Box

(2) SMC: SMC, Z21D: DO-201AD

(3) L: Lead Free, G: Halogen Free and Lead Free

(3)Green Package



MARKING

SMC

DO-201AD

Date Code

Cathode Band for

uni-directional Only

UTC

R3200

L: Lead Free

G: Halogen Free

MBR3200

Date Code

L: Lead Free

G: Halogen Free

Cathode Band for uni-directional Only
