1 / 3 page  UNISONIC TECHNOLOGIES CO., LTD SB540 DIODE www.unisonic.com.tw 1 of 3 Copyright © 2015 Unisonic Technologies Co., Ltd QW-R601-186.F 5.0A SCHOTTKY BARRIER RECTIFIER DESCRIPTION The UTC SB540 is 5.0A schottky barrier rectifier. it uses UTC’s advanced technology to provide customers with high current capability and low forward voltage drop, etc. The UTC SB540 is suitable for free wheeling, low voltage and polarity protection applications, etc. FEATURES * Metal to silicon rectifier, majority carrier conduction. * For use in low voltage, high frequency inverters free wheeling, and polarity protection applications. * Low power loss, high efficiency. * High current capability, low VF. * High surge capacity. ORDERING INFORMATION Ordering Number Pin Assignment Lead Free Halogen Free Package 1 2 Packing SB540L-SMB-R SB540G-SMB-R SMB K A Tape Reel SB540L-SMC-R SB540G-SMC-R SMC K A Tape Reel SB540L-Z21D-B SB540G-Z21D-B DO-201AD K A Tape Box Note: Pin Assignment: A: Anode K: Cathode SB540L-SMB-R (1)Packing Type (2)Package Type (1) R: Tape Reel, B: Tape Box (2) SMB: SMB, SMC: SMC, Z21D: DO-201AD (3) L: Lead Free, G: Halogen Free and Lead Free (3)Green Package MARKING SMB / SMC DO-201AD SB540 Date Code L: Lead Free G: Halogen Free Cathode Band for uni-directional Only |
