EM341-RTR Scheda tecnica(PDF) 20 Page - Silicon Laboratories |
|
|
|||||||||||||||||||||||||||||
EM341-RTR Scheda tecnica(HTML) 20 Page - Silicon Laboratories |
|
|
20 / 237 page  EM341 20 Rev 1.0 2.7.3. Synthesizer Table 2.10 lists the key parameters of the integrated synthesizer on the EM341. Table 2.10. Synthesizer Characteristics Measured on Silicon Labs’ EM357 reference design with TA = 25 °C and VDD = 3 V, unless otherwise noted. Parameter Test Condition Min Typ Max Unit Frequency range 2400 — 2500 MHz Frequency resolution — 11.7 — kHz Lock time From off — — 100 μs Relock time Channel change or RX/TX turnaround (IEEE 802.15.4-2003 defines 192 μs turnaround time) — — 100 μs Phase noise at 100 kHz offset — –75 — dBc/Hz Phase noise at 1 MHz offset — –100 — dBc/Hz Phase noise at 4 MHz offset — –108 — dBc/Hz Phase noise at 10 MHz offset — –114 — dBc/Hz |
|
