VCXO2E datasheet(2/2 Pages) MICROCRYSTAL

Il numero della parte	VCXO2E

Spiegazioni elettronici	This SMD oscillator in ceramic package has been specially designed for surface mount using infrared, vapor phase or epoxy techniques.

PDF	2 Pages

Scroll/Zoom	100%

Produttore elettronici	MICROCRYSTAL [MICORO CRYSTAL SWITZERLAND]

Homepage	http://www.microcrystal.com

Logo

2 / 2 page

Version 2.0/08.2015

Micro Crystal AG

Tel.

+41 32 655 82 82

Mühlestrasse 14

Fax

+41 32 655 82 83

CH-2540 Grenchen

sales@microcrystal.com

Switzerland

www.microcrystal.com

ENVIRONMENTAL

CHARACTERISTICS:

Storage temp. range

-55 to +125°C

Vibration resistance

10 to 2000Hz / 40g

Shocks resistance

10000g / 0.3ms / ½ sine

Vc (Voltage control range)

0 to 3.3V

Response Slope

positive

frequency bandwich

≤10kHz

Input impedance

≥100kohm

TERMINATIONS AND

PROCESSING:

Reflowsoldering

260°C / 10s max

Package

Ceramic 5 x 3.2 x 1.6mm

Lids

Ceramic

Terminations option T3 on request

(not available on G temperature range)

with tinned Ag/Cu/Zn

PRODUCT DESCRIPTION AND

ORDERING INFORMATION:

All specifications subject to change without notice.

Frequency «MHz»

12.288

12.8

24.576

25.6

Other frequencies on request

STANDARD FREQUENCIES:

FREQUENCY CONTROLE RANGE:

= Vdd 3.3V

= -40 to 85°C

= -55 to 125°C

= -10 to 150°C

= -10 to 175°C

= -10 to 210°C

= custom

Frequency

option 2

blank Au plasted

T3 = tinned

customer

spec N°

VCXO2E

V - D 20MHz

T3 XXX

TAbLE 1: Idd

(Without load)

Frequency

F=< 10MHz

≤ 20MHz

40MHz

V=Vdd = 3.3V

< 4mA

< 5mA

< 20mA

Auniquepartnumberwillbegeneratedforeachproductspecification

20xxxx-EA00

xxx pcs

(in ESD plastic tray)

200xxx-ML00

xxx pcs

(in tape & reel, any quantity)
