JH43480800A

VER: 1.0

- 3 -

Issue date: 2013/08/15

JEWEL HILL ELECTRONIC CO.,LTD.

1. GENERAL DESCRIPTION.

JH43480800A model is a Color TFT LCD. This main Module has a 4.3 inch diagonally

measured active display area with 480(RGB)×800 resolution. Each pixel is divided into Red,

Green and Blue sub-pixels and dots which are arranged in vertical stripes.

The LCD color is determined with 262,000 colors signal for each pixel.

The JH43480800A has been designed to apply the interface method that enables low

power, high speed, and high contrast.

JH43480800A is intended to support applications where thin thickness, wide viewing

angle and low power are critical factors and graphic displays are important.

2. GENERAL FEATURES.

Item

Display Panel

Remark

Display Mode

Normally White, Transmissive LCD

Viewing Direction

9H

Input Signals

8/16BIT

Outside Dimensions

62.46(W)*105.9(H)*2.3(T)

Effective Area

-

Active Area

56.16mm(W)×93.6mm(H)

Number of Pixels

480×RGB×800Pixels

Pixel Pitch

0.117mm(H)×0.117mm(W)

Pixel Arrangement

RGB Vertical stripes

Drive IC

NT35510

3.Absolute Maximum Ratings

The following are maximum values which, if exceeded may cause operation or damage to

the unit.

ITEM

Symbol

Min.

Typ.

Max.

Unit

Remark

Power for Circuit Driving

VDD

-0.3

-

3.3

V

Power for Circuit Logic

VCI

-0.3

-

4.6

V

LC Operating Voltage *1)

Vop

-

V

LED Forward Voltage

25.4

25.6

25.8

V

LED Forward Current

If

-

15

-

mA

LED Luminance

4000

-

-

Storage Humidity

10

-

90

%RH

Storage Temperature

T

BBBBBBBBB

ST

BBBBBBBBB

-30

-

80

℃

Operating Ambient Humidity

H

BBBBBBBBB

OP

BBBBBBBBB

10

-

90

%RH

Operating Ambient temperature

T

BBBBBBBBB

OP

BBBBBBBBB

-20

-

70

℃

At

25±5℃
