JH43480800ACNLWNTHCWC Scheda tecnica(PDF) 10 Page - Jewel Hill Electronic |
|
|
|||||||||||||||||||||||||||||
JH43480800ACNLWNTHCWC Scheda tecnica(HTML) 10 Page - Jewel Hill Electronic |
|
|
10 / 23 page  JH43480800A VER: 1.0 - 9 - Issue date: 2013/08/15 JEWEL HILL ELECTRONIC CO.,LTD. 7.Pin Description Pin NO. Symbol Description 1 GND Ground 2 LED_A LED+ 3 LED_K LED- 4 NC NC 5 NC NC 6 NC NC 7 NC NC 8 IM0 The MPU system 8/16Bits interface mode select pin 0 9 GND Ground 10 IOVCC Power Supply(2.8V/1.8V) 11 VCC Power Supply2.8V 12 GND Ground 13 NC/ID NC 14 CS Chip select input pin 15 RS Data/Command Write Select pin 16 WR Write execution control pin 17 RD Read execution control pin 18 RESET System Reset Pin 19 FMARK FMARK 20 GND Ground 21 GND Ground 22-37 DB15-DB0 Data Bus 38 GND Ground 39 LEDPWN NC 40 GND Ground |
|
|
