JH47480272A

VER: 0.1

- 27 -

Issue date: 2013/08/01

JEWEL HILL ELECTRONIC CO.,LTD.

Others.

Liquid crystals solidify under low temperature (below the storage temperature range)

leading to defective orientation or the generation of air bubbles (black or white). Air

bubbles may also be generated if the module is subject to a low temperature.

If the LCD modules have been operating for a long time showing the same display

patterns, the display patterns may remain on the screen as ghost images and a slight

contrast irregularity may also appear. A normal operating status can be regained by

suspending use for some time. It should be noted that this phenomenon does not

adversely affect performance reliability.

To minimize the performance degradation of the LCD modules resulting from destruction

caused by static electricity etc., exercise care to avoid holding the following sections when

handling the modules.

- Exposed area of the printed circuit board.

-Terminal electrode sections.
