3 / 6 page

(L)(mm)

Standard Tolerance (mm)

sHow to Specify Cable Assembly

q Ordering Information

q Standard tolerances for (L)**

L(mm)

Double-ended cable assembly

L(mm)

Single-ended cable assembly

sReceptacle

0.3

0.85

0.25

0.3

1.7

SIGNAL TERMINAL

GND

BRecommended PCB Mounting Pattern

GND

No conductive traces in this area

2.6

1.4

0.5

SIGNAL

TERMINAL

PAD

Series name

Assembly type

Cable type

Cable color

Total length (mm)

W.FL

LP2: Single ended

2LP: Double ended

04N: 0.81mm dia. ultra-fine coaxial cable

1: White, 2: Black

Length (L)

*L=35 to 200

±4

L=200 to 500

±8

L=500 to 1000

±12

L=1000 /

±1.5% of (L)

Part Number

CL No.

Packaging

331-0482-6-10

Reel packaging (2000 pieces/reel)

W.FL-R-SMT-1(10)

Weight / EA

5.6 mg

-- (L)

[[ ]]

04N

2LP

W.FL

*Minimum available length (L) is 35mm

**Contact nearest HRS representative if different

tolerances are required.

***Contact Nearest HRS representative if one end

requires preparation.

Recommended screen thickness: 0.1mm to 0.12mm

***
