4-Port Desktop KVM Switch (USB)

MODEL NUMBER: B006-VU4-R

Description

Tripp Lite's 4-port Desktop USB KVM Switch is the optimal solution for controlling up to 4 USB computers from

one VGA monitor and USB keyboard/mouse. Manually switch between connected computers using pushbuttons

or hotkey controls; or, monitor connected computers automatically via Auto Scan Mode. The B006-VU4-R is

operating system independent, and works with all computers that have an available VGA and USB port. It

supports video resolutions up to 2048 x 1536, and features a compact design that does not require software or

complicated set-up procedures. Constructed of heavy-duty steel housing. Order P758 Cables separately.

Features

Control up to 4 USB computers from a single VGA monitor and USB keyboard/mouse

Order P758 Cables separately

Port LEDs illuminate Light Orange to indicate a computer is connected, and Bright Orange to indicate it is the selected port

Supports video resolutions up to 2048 x 1536, DDC2B

No software or complicated set-up procedures required

Manually switch between connected computers via front panel pushbuttons or hotkey commands

Automatically monitor connected computers via Auto Scan Mode

Compatible with all major operating systems

Compatibile with most mice; including scroll mice

Constructed of heavy-duty steel housing

Specifications

OVERVIEW

Users

1

AC Adapter

Input: 100-240V, 50/60Hz, 0.5A / Output: 5.3V, 190mA

Highlights

Control up to 4 USB computers

from a single VGA monitor and

USB keyboard/mouse

Switch between connected

computers via pushbuttons or

hotkey commands

Auto Scan Mode allows

monitoring of connected

computers without manually

switching between them

Compatible with all major

operating systems

Supports video resolutions up to

2048 x 1536, DDC2B

Package Includes

B006-VU4-R 4-port USB KVM

Switch

External Power Supply with

NEMA 1-15P Plug (Input:

100-240V, 50/60Hz, 0.5A /

Output: 5.3V, 190mA)

Owner's manual
