background image
D a t a S h e e t
68
MB9B410R-DS706-00026-3v0-E, March 11, 2015
CONFIDENTIAL
2.
Recommended Operating Conditions
(VSS = AVSS = 0.0V)
Parameter
Symbol
Conditions
Value
Unit
Remarks
Min
Max
Power supply voltage
VCC
-
2.7*
2
5.5
V
Analog power supply voltage
AVCC
-
2.7
5.5
V
AVCC = VCC
Analog reference voltage
AVRH
-
2.7
AVCC
V
Smoothing capacitor
CS
-
1
10
μF
For built-in
regulator*
1
Operating
temperature
FPT-100P-M20/M23
FPT-120P-M21/M37
TA
When
mounted on
four-layer
PCB
- 40
+ 85
°C
FPT-100P-M36
BGA-112P-M04
TA
-
- 40
+ 85
°C
*1: See "
· C Pin" in "■ Handling Devices" for the connection of the smoothing capacitor.
*2: In between less than the minimum power supply voltage and low voltage reset/interrupt detection voltage
or more, instruction execution and low voltage detection function by built-in High-speed CR(including
Main PLL is used) or built-in Low-speed CR is possible to operate only.
<WARNING>
The recommended operating conditions are required in order to ensure the normal operation of the
semiconductor device. All of the device's electrical characteristics are warranted when the device is
operated within these ranges.
Always use semiconductor devices within their recommended operating condition ranges. Operation
outside these ranges may adversely affect reliability and could result in device failure. No warranty is made
with respect to uses, operating conditions, or combinations not represented on the data sheet. Users
considering application outside the listed conditions are advised to contact their representatives beforehand.
