Micro Crystal
Real Time Clock / Calendar Module
RV-8564
7/40
5. PIN DESCRIPTION
Symbol
Pin #
Description
C2
C3
VDD
1
2
Positive supply voltage
CLKOUT
2
3
Clock Output pin; push-pull
N.C.
3
8
Not Connected
SCL
4
4
Serial Clock Input pin; requires pull-up resistor
SDA
5
5
Serial Data Input-Output pin; open-drain; requires pull-up resistor
VSS
6
7
Ground
INT
7
6
Interrupt Output pin; open-drain; active LOW
N.C.
8
9
Not Connected
N.C.
9
10
Not Connected
CLKOE
10
1
CLKOUT enable/disable pin; enable is active HIGH; tie to GND when not using CLKOUT
