Product Search Data Sheet

SFECF10M7GA00-R0

Specifications

Operating Temperature Range

-

℃

20

to

℃

80

Shape

SMD

Elements

2

Center Frequency

10.700MHz

Center Frequency Tolerance

±30kHz

Nominal Center Value

No

3dB Bandwidth

230kHz±50kHz

Stop Bandwidth

510kHz

Area of Stop Bandwidth

[within 20dB]

Spurious Attenuation

30dB[within 9MHz to fo]

Insertion Loss

3.5dB±2.0dB(at minimum loss point)

Ripple

1.0dBmax.(at minimum loss point)

Input/Output Impedance

330Ω

2 of 3

Atten ti o n

1.T his datasheet is downloaded from the website of Murata Manufacturing Co., Ltd. T herefore, it’s specifications are subject to change or our products in it may be discontinued

without advance notice. Please check with our sales representatives or product engineers before ordering.

2.T his datasheet has only typical specifications because there is no space for detailed specifications.

T herefore, please review our product specifications or consult the approval sheet for product specifications before ordering.
