Product Search Data Sheet

SFSCE10M7WF04-R0

Specifications

Operating Temperature Range

-

℃

20

to

℃

80

Shape

SMD

Elements

2

Center Frequency

10.700MHz

Nominal Center Value

Yes

3dB Bandwidth

fn±400.0kHzmin.

Stop Bandwidth

1.8MHz

Area of Stop Bandwidth

[within 20dB]

Spurious Attenuation

25dB[within 5.7MHz to fn / fn to

15.7MHz]

Insertion Loss

6.0dB[at minimum loss point]

Ripple

1.5dB[within 3dB Bandwidth]

GDT Deviation

0.6μs[within fn±325kHz]

Input/Output Impedance

470Ω

2 of 3

Atten ti o n

1.T his datasheet is downloaded from the website of Murata Manufacturing Co., Ltd. T herefore, it’s specifications are subject to change or our products in it may be discontinued

without advance notice. Please check with our sales representatives or product engineers before ordering.

2.T his datasheet has only typical specifications because there is no space for detailed specifications.

T herefore, please review our product specifications or consult the approval sheet for product specifications before ordering.

URL : http://www.murata.com/

Last

：

updated 2016/06/24
