Addressing Modes

There are ten addressing modes, six for operand addressing

and four for transfer of control.

OPERAND ADDRESSING MODES

This is the “normal” addressing mode. The operand is the

data memory addressed by the B pointer or X pointer.

decrement of pointer)

This addressing mode is used with the LD and X instruc-

tions. The operand is the data memory addressed by the B

pointer or X pointer. This is a register indirect mode that au-

tomatically post increments or decrements the B or X regis-

ter after executing the instruction.

Direct

The instruction contains an 8-bit address field that directly

points to the data memory for the operand.

Immediate

The instruction contains an 8-bit immediate field as the oper-

and.

Short Immediate

This addressing mode is used with the Load B Immediate in-

struction. The instruction contains a 4-bit immediate field as

the operand.

Indirect

This addressing mode is used with the LAID instruction. The

contents of the accumulator are used as a partial address

(lower 8 bits of PC) for accessing a data operand from the

program memory.

TRANSFER OF CONTROL ADDRESSING MODES

Relative

This mode is used for the JP instruction, with the instruction

field being added to the program counter to get the new pro-

gram location. JP has a range from −31 to +32 to allow a

1-byte relative jump (JP + 1 is implemented by a NOP in-

struction). There are no “pages” when using JP, since all 15

bits of PC are used.

Absolute

This mode is used with the JMP and JSR instructions, with

the instruction field of 12 bits replacing the lower 12 bits of

the program counter (PC). This allows jumping to any loca-

tion in the current 4k program memory segment.

Absolute Long

This mode is used with the JMPL and JSRL instructions, with

the instruction field of 15 bits replacing the entire 15 bits of

the program counter (PC). This allows jumping to any loca-

tion up to 32k in the program memory space.

Indirect

This mode is used with the JID instruction. The contents of

the accumulator are used as a partial address (lower 8 bits of

PC) for accessing a location in the program memory. The

contents of this program memory location serve as a partial

address (lower 8 bits of PC) for the jump to the next instruc-

tion.

Note: The VIS is a special case of the Indirect Transfer of Control addressing

mode, where the double byte vector associated with the interrupt is

transferred from adjacent addresses in the program memory into the

program counter (PC) in order to jump to the associated interrupt ser-

vice routine.

Instruction Set

Registers

8-Bit Accumulator Register

8-Bit Address Register

8-Bit Segment Register

8-Bit Stack Pointer Register

15-Bit Program Counter Register

Upper 7 Bits of PC

Lower 8 Bits of PC

1 Bit of PSW Register for Carry

1 Bit of PSW Register for Half Carry

GIE

1 Bit of PSW Register for Global Interrupt

Enable

Interrupt Vector Upper Byte

Interrupt Vector Lower Byte

Symbols

[B]

Memory Indirectly Addressed by B Register

[X]

Memory Indirectly Addressed by X Register

Direct Addressed Memory

Mem

Direct Addressed Memory or [B]

Meml

Direct Addressed Memory or [B] or

Immediate Data

Imm

8-Bit Immediate Data

Reg

(Includes B, X and SP)

Bit

Bit Number (0 to 7)

←

Loaded with

↔

Exchanged with
