IXD_604

R07

www.ixysic.com

13

5.4.6 Tape & Reel Information for D2 Package

Dimensions

mm MIN / mm MAX

(inches MIN / inches MAX)

5.00 BSC

(0.197 BSC)

4.00 BSC

(0.157 BSC)

0.80 / 1.00

(0.031 / 0.039)

0.10

(0.004)

0.95 BSC

(0.037 BSC)

0.74 / 0.83

(0.029 / 0.033)

0.30 / 0.45

(0.012 / 0.018)

3.03 / 3.10

(0.119 / 0.122)

2.53 / 2.60

(0.100 / 0.102)

0.35 / 0.45 x 45º

(0.014 / 0.018 x 45º)

Pin 1

Pin 1

Pin 8

0.20 REF

(0.008 REF)

Recommended PCB Land Pattern

4.50

(0.177)

0.45

(0.018)

1.20

(0.047)

3.10

(0.122)

2.60

(0.102)

0.95

(0.037)

0.35 x 45º

(0.014 x 45º)

NOTE:

The exposed metal pad on the back of the D2 package should

be connected to GND. Pad is not suitable for carrying current.

K

B

5º MAX

A

5º MAX

0.30 ± 0.05

(0.05)

(0.05)

R0.75 TYP

8.00 ± 0.10

2.00 ± 0.05

4.00 ± 0.10 See Note #2

12.00 ± 0.30

5.50 ± 0.05

1.75 ± 0.10

∅1.50 (MIN)

∅1.55 ± 0.05

NOTES:

1. A

2. 10 pitches cumulative tol. ± 0.2mm

3. ( ) Reference dimensions only.

4. Unless otherwise specified, all dimensions in millimeters.

Embossment

Embossed Carrier

Top Cover

Tape Thickness

0.102 MAX.

(0.004 MAX.)

330.2 DIA.

(13.00 DIA.)
