TPS650830
www.ti.com
SLVSCF4A – DECEMBER 2014 – REVISED JULY 2016
Submit Documentation Feedback
Product Folder Links: TPS650830
Specifications
Copyright © 2014–2016, Texas Instruments Incorporated
Electrical Characteristics (continued)
Over recommended free-air temperature range and over recommended input voltage range (typical at an ambient
temperature range of 25°C) (unless otherwise noted)
PARAMETER
TEST CONDITIONS
MIN
TYP
MAX
UNIT
TVSx_POWERGOO
D_DEGLITCH
Powergood deglitch time for both
rising and falling edges
VSx voltage must cross powergood
threshold and stay for at least this time to
change powergood output
state.Measured from VSx into or out of
powergood threshold, until PGx toggles,
for both rising and falling edges.
27
30
33
μs
EMBEDDED CONTROLLER RESET
VOL_OD
EC_RSTZ output low voltage
IOL = 2 mA, VEC_RST = 3.3 V
0.4
V
ILKG_OD
EC_RSTZ leakage current
Output buffer in open-drain mode,
VEC_RST = 3.3 V
0.01
0.2
µA
EC_RST time duration (Trst)
Reset timer register value: 00
20
ms
EC_RST time duration (Trst)
Reset timer register value: 01
40
ms
EC_RST time duration (Trst)
Reset timer register value: 10
80
ms
EC_RST time duration (Trst) -
Default setting
Reset timer register value: 11
200
ms
ILK
ECVCC input quiescent current
3
µA
ECVCC voltage threshold (Vth)
Reset Voltage Threshold register value:
000
1.344
1.4
1.456
V
ECVCC voltage threshold (Vth)
Reset Voltage Threshold register value:
001
1.44
1.5
1.56
V
ECVCC voltage threshold (Vth)
Reset Voltage Threshold register value:
010
1.536
1.6
1.664
V
ECVCC voltage threshold (Vth)
Reset Voltage Threshold register value:
011
1.632
1.7
1.768
V
ECVCC voltage threshold (Vth)
Reset Voltage Threshold register value:
100
2.304
2.4
2.496
V
ECVCC voltage threshold (Vth)
Reset Voltage Threshold register value:
101
2.496
2.6
2.704
V
ECVCC voltage threshold (Vth)
Reset Voltage Threshold register value:
110
2.688
2.8
2.912
V
ECVCC voltage threshold (Vth)
Reset Voltage Threshold register value:
111
2.88
3.0
3.12
V
POWER PATH COMPARATORS and CRITICAL SUPPLY VOLTAGE (ACIN, BAT1, BAT2, VDCSNS)
Output low saturation voltage for
open-drain logic output pin
(TRIPZ)
Comparator input voltage > internal
reference voltage. Output pulling low,
Sink current = 5 mA
0.5
V
IOUT VCOMP- internal current
source
Current out of the VCOMP pin when
IOUT VCOMP enabled
9.5
10
10.6
μA
VREF_VCOMP_rising, internal
reference voltage
Rising voltage at VCOMP pin, changes
TRIPZ to logic low
1.211
1.223
1.235
V
VHYST VCOMPFalling, internal
hysteresis voltage
Falling voltage at VCOMP pin, changes
TRIPZ to logic high
61
mV
Output low saturation voltage for
open-drain logic output pin
(ACSWONZ, BAT1SWONZ,
BAT2SWONZ)
Comparator input voltage > internal
reference voltage. Output pulling low,
Sink current = 5 mA
0.5
V
ILKG
ACIN, BAT1, BAT2 - Current
leakage
Current into the ACIN, BAT1, or BAT2
pins from 5.4 V - 24 V (when pin is below,
at, or above 6-V internal protection
switch.)
0.1
μA
VREF_PP
VREF_ACIN_rising - Internal
reference voltage
Rising voltage at ACIN pin, makes
ACSWONZ trigger low
1.2365
1.25
1.2645
V
VHYST_PP
VHYST_ACIN_falling - Internal
hysteresis voltage
Falling voltage with respect to
VREF_ACIN at ACIN pin, makes
ACSWONZ trigger high
125
mV
