5 / 5 page

CJS

SLIDE SWITCHES (SMD)

■ PACKAGING SPECIFICATIONS

O Taping version is packaged in 1000 pcs. per reel.

Orders will be accepted for units of 1000 pcs., i.e., 1000,

2000, 3000 pcs., etc.

O Taping version is boxed with two reels (2000 pcs.).

Maximum number of consecutive missing pieces=2

Leader length and reel dimension are shown in the

diagrams below:

O Embossed tape dimensions

O Reel dimensions

(Unit: mm)

(Conforms to JIS C 0806)

40 mm min.

20 pitches min.

400 mm min.

Direction of feed

End

Head

Empty

Filled

Empty

Leader

21.4

± 1

17.4

± 1

±0.5

±0.2

±0.8

(Conforms to JIS C 0806)

O Boxing of bulk pack in a plastic bag is performed with

100 pcs. (standard 500 pcs.) per box.

Terminal No.1

Direction of feed

(CJS-1200B1)

1.5

8 0.1

4 0.1

2 0.1

0.3 0.1

Installation example

+0.1

O CJS-1200TA□ , 1200TB□ , 1201TA□ , 1201TB□

(Unit: mm)
