Type

Configuration

Part Number

SJ Drawing

Applicable Wire

Outer

Diameter

Socket

Contact

(Crimp)

Contacts in

pieces

(100 pcs.)

JN1-22-20S-R-PKG100

SJ035503

20, 21AWG

Dia. 1.5 max.

JN1-22-22S-PKG100

21 to 25AWG

Dia. 1.5 max.

JN1-22-26S-PKG100

26 to 28AWG

Dia. 1.1 max.

Contacts in

reel

(10,000 pcs.)

JN1-22-20S-R-10000

SJ035504

20, 21AWG

Dia. 1.5 max.

JN1-22-22S-10000

21 to 25AWG

Dia. 1.5 max.

JN1-22-26S-10000

26 to 28AWG

Dia. 1.1 max.

Pin

Contact

(Crimp)

Contacts in

pieces

(100 pcs.)

JN1-22-20P-R-PKG100

SJ037430

20, 21AWG

Dia. 1.5 max.

JN1-22-22P-PKG100

21 to 25AWG

Dia. 1.5 max.

JN1-22-26P-PKG100

26 to 28AWG

Dia. 1.1 max.

Contacts in

reel

(10,000 pcs.)

JN1-22-20P-R-10000

SJ037431

20, 21AWG

Dia. 1.5 max.

JN1-22-22P-10000

21 to 25AWG

Dia. 1.5 max.

JN1-22-26P-10,000

26 to 28AWG

Dia. 1.1 max.

JN2/W

■ Chart of Crimp Tool ( The same as JN1 / 2 Series)

Note 1: The * in the part number will stand for P: Pin Contact, S: Socket Contact.

Note 2: Please contact us concerning connection tool, contact removal tool and the RoHS compliance of the

tools for this series.

Note 3: When using 350-D02-2, adjustment of tool will be needed.

Type of Tool

Instruction

Manual for

Tooling

Applicable

Tooling

Applicable

Wire

Outer

Diameter

Part Number of

Applicable Crimp

Contact (Note 1)

Hand Crimp

(for contacts in

pieces)

T700253

CT150-2-JN1-D

20, 21AWG

Dia.1.3 to 1.5

JN1-22-20*-R-PKG100

25AWG

Dia.0.8 to 1.0

JN1-22-22*-PKG100

CT150-2-JN1-E

21, 23AWG

Dia.1.0 to 1.5

JN1-22-22*-PKG100

25AWG

Dia.0.8 to 1.0

T700238

CT150-2-JN1-B

22, 24AWG

Dia.1.0 to 1.3

JN1-22-22*-PKG100

26, 28AWG

Dia.0.8 to 1.0

JN1-22-26*-PKG100

Semi-

automatic

Crimp

(for contacts in

reel)

T703294

350-JN1-2C

20 to

28AWG

Dia.0.8 to 1.5

JN1-22-20*-R-10000

JN1-22-22*-10000

JN1-22-26*-10000

T703413

350-D02-2

(Note 3)
