UNISONIC TECHNOLOGIES CO., LTD

BC846AS

Preliminary

DUAL TRANSISTOR

www.unisonic.com.tw

1 of 3

QW-R221-036 .a

DUAL NPN SURFACE MOUNT

SMALL SIGNAL TRANSISTOR



DESCRIPTION

The UTC BC846AS is a dual NPN surface mount small signal

transistor, it uses UTC’s advanced technology to provide customers

with high DC current gain, etc.

The UTC BC846AS is suitable for switching and AF amplifier

applications.



FEATURES

* Suitable for automatic insertion in thick and thin-film circuits

* Switching and AF Amplifier Applications



EQUIVALENT CIRCUIT



ORDERING INFORMATION

Pin Assignment

Ordering Number

Package

1

2

3

4

5

6

Packing

BC846ASG-AL6-R

SOT-363

E1

B1

C2

E2

B2

C1

Tape Reel

Note: Pin Assignment: E: Emitter

B: Base C: Collector

BC846ASG-AL6-R

(1)Packing Type

(2)Package Type

(1) R: Tape Reel

(2) AL6: SOT-363

(3) G: Halogen Free and Lead Free

(3)Green Package



MARKING

8ASG

12

3

4

5

6
