DTC144V
Advance
NPN SILICON TRANSISTOR
UNISONIC TECHNOLOGIES CO., LTD
2 of 3
www.unisonic.com.tw
QW-R221-035.a
ABSOLUTE MAXIMUM RATINGS (TA= 25°C, unless otherwise specified)
Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
ELECTRICAL CHARACTERISTICS (TA= 25°C, unless otherwise specified)
PARAMETER
SYMBOL
TEST CONDITIONS
MIN
TYP
MAX UNIT
VIN(OFF)
VCC= 5V, IOUT=100μA
0.5
Input Voltage
VIN(ON)
VOUT= 0.3V, IOUT= 20mA
3
V
Output Voltage
VOUT(ON)
IOUT/IIN= 10mA / 0.5mA
0.1
0.3
V
Input Current
IIN
VIN= 5V
0.18
mA
Output Current
IOUT(OFF)
VCC= 50V , VIN=0V
0.5
μA
DC Current Gain
hFE
VOUT= 5V, IOUT= 5mA
33
Input Resistance
R1
32.9
47
61.1
kΩ
Resistance Ratio
R2
10
kΩ
Transition Frequency
fT
VCE= 10V, IE= -5mA, f=100MHz
250
MHz
PARAMETER
SYMBOL
RATINGS
UNIT
Supply Voltage
VCC
50
V
Input Voltage
VIN
-10 ~ +40
V
IOUT
100
mA
Output Current
IOUT(MAX)
100
mA
Power Dissipation
PD
200
mW
Junction Temperature
TJ
+150
°C
Storage Temperature
TSTG
-55~+150
°C
