2 / 5 page

BCP53 Series

www.onsemi.com

ELECTRICAL CHARACTERISTICS (TA = 25°C unless otherwise noted)

Characteristics

Symbol

Min

Typ

Max

Unit

OFF CHARACTERISTICS

Collector−Base Breakdown Voltage

(IC = −100 mAdc, IE = 0)

V(BR)CBO

−100

−

Vdc

Collector−Emitter Breakdown Voltage

(IC = −1.0 mAdc, IB = 0)

V(BR)CEO

−80

−

Vdc

Collector−Emitter Breakdown Voltage

(IC = −100 mAdc, RBE = 1.0 kW)

V(BR)CER

−100

−

Vdc

Emitter−Base Breakdown Voltage

(IE = −10 mAdc, IC = 0)

V(BR)EBO

− 5.0

−

Vdc

Collector−Base Cutoff Current

(VCB = − 30 Vdc, IE = 0)

ICBO

−

−100

nAdc

Emitter−Base Cutoff Current

(VEB = − 5.0 Vdc, IC = 0)

IEBO

−

−10

mAdc

ON CHARACTERISTICS

DC Current Gain

(IC = − 5.0 mAdc, VCE = − 2.0 Vdc)

All Part Types

(IC = −150 mAdc, VCE = − 2.0 Vdc)

BCP53, SBCP53

BCP53−10, SBCP53−10

BCP53−16, SBCP53−16, NSVBCP53−16

(IC = − 500 mAdc, VCE = − 2.0 Vdc)

All Part Types

hFE

100

−

250

160

250

−

Collector−Emitter Saturation Voltage

(IC = − 500 mAdc, IB = − 50 mAdc)

VCE(sat)

−

− 0.5

Vdc

Base−Emitter On Voltage

(IC = − 500 mAdc, VCE = − 2.0 Vdc)

VBE(on)

−

−1.0

Vdc

DYNAMIC CHARACTERISTICS

Current−Gain − Bandwidth Product

(IC = −10 mAdc, VCE = − 5.0 Vdc, f = 35 MHz)

−

MHz

Product parametric performance is indicated in the Electrical Characteristics for the listed test conditions, unless otherwise noted. Product

performance may not be indicated by the Electrical Characteristics if operated under different conditions.
