ADA4522-1ARMZ-R7 datasheet(7/32 Pages) AD

7 / 32 page

Data Sheet

ADA4522-1/ADA4522-2/ADA4522-4

Rev. E | Page 7 of 32

ABSOLUTE MAXIMUM RATINGS

Table 5.

Parameter

Rating

Supply Voltage

60 V

Input Voltage

(V−) − 300 mV to (V+) + 300 mV

Input Current1

±10 mA

Differential Input Voltage

±5 V

Output Short-Circuit

Duration to Ground

Indefinite

Temperature Range

Storage

−65°C to +150°C

Operating

−40°C to +125°C

Junction

−65°C to +150°C

Lead Temperature (Soldering,

60 sec)

300°C

The input pins have clamp diodes to the power supply pins. Limit the input

current to ±10 mA or less whenever input signals exceed the power supply

rail by 300 mV.

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

THERMAL RESISTANCE

θJA is specified for the worst case conditions, that is, a device

soldered in a circuit board for surface-mount packages using a

standard 4-layer JEDEC board.

Table 6. Thermal Resistance

Package Type

θJA

θJC

Unit

8-Lead MSOP (RM-8)

194

°C/W

8-Lead SOIC (R-8)

122

°C/W

14-Lead TSSOP (RU-14)

112

°C/W

14-Lead SOIC (R-14)

115

°C/W

ESD CAUTION
