ADA4610-1/ADA4610-2/ADA4610-4

Data Sheet

Rev. G | Page 6 of 25

ABSOLUTE MAXIMUM RATINGS

Table 4.

Parameter

Rating

Supply Voltage

±18 V

Input Voltage

±VS

Input Current1

±10 mA

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +125°C

Junction Temperature Range

−65°C to +150°C

Lead Temperature (Soldering, 10 sec)

300°C

Electrostatic Discharge (Human Body Model)2

2500 V

Field Induced Charge Device Model (FICDM)3

1250 V

The input pins have clamp diodes connected to the power supply pins. Limit

the input current to 10 mA or less whenever input signals exceed the power

supply rail by 0.3 V.

ESDA/JEDEC JS-001-2011 applicable standard.

JESD22-C101 (ESD FICDM standard of JEDEC) applicable standard.

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

THERMAL RESISTANCE

Table 5. Thermal Resistance

Package Type

θJA1

θJC

Unit

5-Lead SOT-23

219.4

155.6

°C/W

8-Lead SOIC

120

°C/W

8-Lead LFCSP

°C/W

8-Lead MSOP

142

°C/W

14-Lead SOIC

115

°C/W

16-Lead LFCSP

3.2

°C/W

θJA is specified for worst-case conditions, that is, θJA is specified for a device

soldered in a circuit board for surface-mount packages.

ESD CAUTION
