ADP1050
Data Sheet
Pin No.
Mnemonic
Description
20
RTD
Thermistor Input. Place a thermistor (R25 = 100 kΩ (1%), beta = 4250 (1%)) in parallel with a 16.5 kΩ (1%) resistor
and a 1 nF filtering capacitor. This pin is referred to AGND. If this pin is not used, connect it to AGND.
EP
Exposed Pad. The ADP1050 has an exposed thermal pad on the underside of the package. For increased reliability
of the solder joints and maximum thermal capability, it is recommended that the exposed pad be soldered to the
PCB AGND plane.
Rev. A | Page 10 of 92
